PVC Photoluminescent Rigid Sheet
PVC Photoluminescent Rigid Sheet Overview
PVC Photoluminescent Rigid Sheet Specification
| Model | Thickness (mm) | Size | Afterglow Intensity (mcd/㎡) | Luminance Class (ISO 17398/PSPA) | Appearance Color (Daytime) | Glowing color (Night) | |
| 10 min | 60 min | ||||||
| MH-B-G050 | 1.0 | 1m × 1.2m or 0.5m × 0.6m | >70 | >10 | Class B |
Light-yellow |
|
| MH-B-G100 | 1.1 | >100 | >14 | Class B+ | |||
| MH-B-G150 | 1.2 | >150 | >20 | Class C | |||
| MH-B-G200 | 1.2 | >210 | >30 | Class C+ | |||
| MH-B-G300 | 1.3 | >300 | >35 | Class D | |||
| MH-B-G500 | 1.6 | >500 | >68 | Class E+/F- | |||
| MH-B-G700 | 1.6 | >700 | >90 | Class G | |||
| MH-B-B200 | 1.2 | >170 | >15 | Class B+ |
Light-white |
Blue-green |
|
Note:
1. Test standard: DIN 67510-1. Measured under D65 standard light source after excitation for 5 min at 1,000 lux.
2. Class C (MH-B-G150 photoluminescent rigid sheet) is the recommended minimum for safety signage and evacuation systems per ISO 16069, ISO 17398 and PSPA.
3. We also make aluminum photoluminescent rigid sheet and PET photoluminescent rigid sheet.
Ready to order or want a sample for evaluation?
Tell us your grade, size, and quantity — we will provide pricing within 24 hours.
Customization Service
We provide customization service for glow in the dark rigid sheet including: thickness, size, glow in the dark color, afterglow intensity, surface (matte or glossy), and self-adhesive backing.
For sign printing service, please send us your design, luminance requirement, and quantity for a quotation.
Why Source Photoluminescent Rigid Sheet From Minhui Luminous
Founded in 2003, Zhejiang Minhui Luminous Technology Co., Ltd. is one of China's most established and largest photoluminescent material manufacturers, and one of the few in the world with full vertical integration from raw pigment synthesis to finished rigid sheet production.. Our 47,000 m² factory supplies innovative and sustainable photoluminescent solutions to clients across 50+ countries.
● Stable Supply: From the raw material photoluminescent pigment used to finished photoluminescent rigid sheet, everything is made in house. We operate 7 kiln lines for photoluminescent pigment and 9 automated coating and lamination lines, with an annual glow in the dark board output exceeding 15 million m².
● Tested Quality Control: Every production batch of our glow in the dark rigid sheet is strictly tested for luminance, strength, weatherproof-ness, and print compatibility.
● R&D Capability for Customization: We can develop photoluminescent rigid sheet tailored to your specific requirement, or deliver ready-to-use photoluminescent signs per your design. Backed with our 5 specialized laboratories, 200+ global patents, and annual R&D investment of over 500,000 USD.
● Setting Photoluminescent Standard: Minhui is a management member of the Photoluminescent Safety Products Association (PSPA), a member of the China Rare Earth Association, and a key contributor to 3 national and industry standards for photoluminescent products in China. We don't just manufacture to standards, we create them.
● Global OEM/ODM: Operating under ISO 9001 quality management,w are the behind-the-scenes manufacturer for recognised brands across the world.
Need Custom Sizes or Direct Factory Quote?
23 YEARS
ISO 9001
Share your project details with us for model recommendation and factory pricing. 24-Hour Response.
Frequently Asked Questions
After 10–20 minutes of charging under any light source (sunlight, UV light, indoor lighting), our PVC photoluminescent rigid sheet can glow in the dark for over 12 hours (decay to 0.3mcd/sqm).
According to ISO 17398 and PSPA (Photoluminescent Safety Products Association) classification, our glow in the dark rigid sheet ranges from Class A to the highest luminance level Class G. No matter you want to make consumer or decorative products, or professional safety signage, our rigid sheet are both the great choice.
If a supplier only claims their photoluminescent rigid sheet can "glows for 4 hours" or "8 hours," that figure is a marketing term, not a technical one. Because human eyes vary significantly in dark-adaptation sensitivity, and what one person perceives as "still glowing" another may consider invisible. Without the afterglow brightness statistic tested under standard condition, these hour claims have no scientific basis and cannot be verified, reproduced, or compared between products.
Always asks the photoluminescent rigid sheet supplier for: luminance in mcd/m² at 10 min and 60 min, the excitation conditions used, and the test standard referenced. A professional supplier will have no hesitation providing it.
Yes. Our PVC photoluminescent sheets are made with our strontium aluminate-based glow in the dark powder. They are non-toxic, non-radioactive, and safe to use. They are safe for indoor and outdoor use in public buildings, marine vessels, and commercial facilities.
A: Class C or Class D is a sub-classification from the globally recognized performance grading system for photoluminescent materials. ISO 17398 has listed 4 sub-classification: A through D. The PSPA (Photoluminescent Safety Products Association) has listed 7 classes (A through G). Each class specifies the minimum luminance (mcd/m²) the photoluminescent material must maintain at 2, 10, 30, and 60 minutes after the light source is removed.
Class C is the recommended minimum for safety signage and evacuation systems per ISO 16069, ISO 17398 and PSPA.
| Class | 2 min (mcd/m²) | 10 min (mcd/m²) | 30 min (mcd/m²) | 60 min (mcd/m²) |
|---|---|---|---|---|
| A | 108 | 25 | 7 | 3 |
| B | 210 | 50 | 15 | 7 |
| C | 690 | 140 | 45 | 20 |
| D | 1,100 | 260 | 85 | 35 |
| E | 1,800 | 400 | 120 | 55 |
| F | 2,300 | 520 | 155 | 70 |
| G | 3,000 | 650 | 190 | 80 |
Minhui's PVC photoluminescent rigid sheet covers Class B (MH-B-G050) through the highest luminance level Class G (MH-B-G700), the class for each model is shown in the specification table.
For sign customization service, please send us your design, luminance requirement and order quantity, then we will provide you a quotation within 24 hours.
According to ISO 17398 and PSPA (Photoluminescent Safety Products Association) classification, our photoluminescent sheet satisfy the luminance requirement ranges from Class B(MH-B-G050) to the highest luminance level Class G(MH-B-G700). The luminance of our photoluminescent sheet are tested according to DIN 67510-1 standard, tested under D65 light source, 1000LUX, 5 minutes excitation time.
For making safety signage, Class C(MH-B-G150) is the recommended minimum for safety signage and evacuation systems per ISO 16069, ISO 17398 and PSPA.
For other standard compliance such as ASTM-E2073, please consult our sales team for recommendation.
Yes. Our PVC photoluminescent rigid sheets support silk-screen printing (with solvent-based inks), inkjet printing and UV digital printing. The surface is optimized for excellent ink adhesion.
We also provide printing service, simply send us your artwork file and luminance requirement and we can make finished photoluminescent sign blanks ready for installation for you.
Our standard sheet sizes are 1m × 1.2m and 0.5m × 0.6m. For standard items, MOQ starts from 10 sheets. Free samples are available for evaluation before bulk ordering.
We offer full customization including size, thickness, matte or glossy surface finish, and self-adhesive backing. For customization MOQ and lead time, please consult our sales team with details.
We provide worldwide fast shipping, with logistic partner including DHL, FEDEX, UPS, railway, air and sea freight.
